fabric-ca使用（docker实现）

1、启动CA服务

创建目录并且编写文件

mkdir -p /opt/docker/fabric-ca-server
gedit docker-compose.yml

#文件名必须是 docker-compose.yml
########################文本内容###########################
fabric-ca-server:
  image: hyperledger/fabric-ca:1.5.1   #注意这里要更改为你要使用的镜像tag
  container_name: fabric-ca-server
  ports:
    - "7054:7054"
  environment:
    - FABRIC_CA_HOME=/etc/hyperledger/fabric-ca-server
  volumes:
    - "./fabric-ca-server:/etc/hyperledger/fabric-ca-server"
  command: sh -c 'fabric-ca-server start -b admin:adminpw'

#-b admin:adminpw
#admin 是我们指定的用户，我们现在给admin生成证书
#adminpw 是admin的密码

启动服务

docker-compose up -d

docker ps 查看运行情况

然后关闭刚才运行的服务，并且删除

docker stop 容器ID
docker rm容器ID

修改当前目录下 fabric-ca-server/fabric-ca-server-config.yaml文件

gedit fabric-ca-server/fabric-ca-server-config.yaml

affiliations:
   R1:
      - admin
      - dev
      - user
   R2:
      - admin
      - dev
      - user
   R3:
      - admin
      - dev
      - user
   R4:
      - admin
      - dev
      - user

删除当前目录下的fabric-ca-server.db

rm fabric-ca-server/fabric-ca-server.db

重启

docker-compose up -d

2、Fabric CA Server

.
├── docker-compose.yml
└── fabric-ca-server
    ├── ca-cert.pem
    ├── fabric-ca-server-config.yaml
    ├── fabric-ca-server.db
    ├── IssuerPublicKey
    ├── IssuerRevocationPublicKey
    └── msp
        └── keystore
            ├── 365543fff66f5062d3d053e6323e3faa4a9ad8a4fe6ab86df551060c92694351_sk
            ├── IssuerRevocationPrivateKey
            └── IssuerSecretKey

msp ：包含keystore，CA服务器的私钥
ca-cert.pem ：CA服务器生成的admin证书
fabric-ca-server.db ：CA默认使用的嵌入型数据库 SQLite,存储发放证书信息，可以通过sqllite3或其他可视化工具查看详细信息。
fabric-ca-server-config.yaml ：CA服务端的配置文件

3、采用fabric-ca-client来生成证书

mkdir /opt/docker/fabric-ca-client

export FABRIC_CA_CLIENT_HOME=/opt/docker/fabric-ca-client

通过fabric-ca-client程序链接CA服务器并enroll(登录)admin管理员

fabric-ca-client enroll -u http://admin:adminpw@localhost:7054

#admin是用户名
#adminpw是admin的密码
#localhost:7054 fabric-ca-server端口,这是刚刚在docker-compose.yml指定的

可以发现/mnt/ca_client目录下生成了一个fabric-ca-client-config.yaml配置文件，以及msp目录，包含管理员的证书和私钥。有了已经成功enroll（登录）的admin用户，接下来将admin作为管理员来register（登记）一个新用户：R4-admin

通过fabric-ca-client register（登记）R4管理员的证书

fabric-ca-client register --id.name r4-admin --id.secret r4-adminpw --id.type admin --id.affiliation r4.admin

4、登录并获取r4-admin的证书到本地

fabric-ca-client enroll -u http://r4-admin:r4-adminpw@localhost:7054 -M $FABRIC_CA_CLIENT_HOME/r4-admin

#r4-admin:r4-adminpw 对应的用户名和密码
#-M 指定的是r4-admin证书保存的位置

5、查看已颁发所有证书

apt-get install sqlite3 libsqlite3-dev

sqlite3 /opt/docker/fabric-ca-server/fabric-ca-server/fabric-ca-server.db

sqlite> .tables
sqlite> select * from certificates;

fabric整个docker配置

零、整体架构

下面介绍下本文所采用的整体架构
三个组织

  • Org0 —> 组织0
  • Org1 —> 组织1
  • Org2 —> 组织2

组织中的成员

  • Org0: 一个orderer节点,一个Org0的Admin节点
  • Org1: 两个Peer节点,一个Org1的Admin节点,一个Org1的User节点
  • Org2: 两个Peer节点,一个Org2的Admin节点,一个Org2的User节点

四台CA服务器

  • TLS服务器：为网络中所有节点颁发TLS证书，用于通信的加密
  • Org1的CA服务器：为组织1中所有用户颁发证书
  • Org2的Ca服务器：为组织2中所有用户颁发证书
  • Org0的CA服务器：为组织0中所有用户颁发证书

这里的四台CA服务器都是根服务器。彼此之间都是独立的存在，没有任何关系。，也就是说每一个CA服务器生成的证书在其他CA服务器都是不能用的。
介绍完之后，可以进入正题了。

一、CA服务器的配置

1、启动TLS CA服务器

mkdir -p /root/hyperledger/docker-compose/fabric-ca-tls && cd /root/hyperledger/docker-compose/fabric-ca-tls

gedit docker-compose.yaml

version: '2'

networks:
  fabric-ca:
services:
   ca-tls:
     container_name: ca-tls
     image: hyperledger/fabric-ca
     command: sh -c 'fabric-ca-server start -d -b tls-ca-admin:tls-ca-adminpw --port 7052'
     environment:
       - FABRIC_CA_SERVER_HOME=/root/hyperledger/fabric-ca/crypto
       - FABRIC_CA_SERVER_TLS_ENABLED=true
       - FABRIC_CA_SERVER_CSR_CN=ca-tls
       - FABRIC_CA_SERVER_CSR_HOSTS=0.0.0.0
       - FABRIC_CA_SERVER_PORT=7052
       - FABRIC_CA_SERVER_DEBUG=true
     volumes:
       - /root/hyperledger/fabric-ca-tls:/root/hyperledger/fabric-ca
     networks:
       - fabric-ca
     ports:
       - 7052:7052

启动docker容器

docker-compose up -d

同时工作目录/root/hyperledger/fabric-ca/ 下面会出现crypto文件夹

ca-cert.pem文件。这是TLS CA服务器的签名根证书，目的是用来对CA的TLS证书进行验证，同时也需要持有这个证书才可以进行证书的颁发。

多环境下我们需要将它复制到每一台机器上。

1.1 TLS CA服务器注册用户

设置环境变量&登陆

#设置环境变量指定根证书的路径(如果工作目录不同的话记得指定自己的工作目录,以下不再重复说明)
export FABRIC_CA_CLIENT_TLS_CERTFILES=/root/hyperledger/fabric-ca-tls/crypto/ca-cert.pem
#设置环境变量指定CA客户端的HOME文件夹
export FABRIC_CA_CLIENT_HOME=/root/hyperledger/fabric-ca-tls/admin
#登录管理员用户用于之后的节点身份注册
fabric-ca-client enroll -d -u https://tls-ca-admin:tls-ca-adminpw@0.0.0.0:7052 --tls.certfiles /root/hyperledger/fabric-ca-tls/crypto/ca-cert.pem

登陆成功后会在/root/hyperledger/fabric-ca-tls/目录下生车给你admin文件夹，这里面是 admin相关的证书文件，并且只有登陆了admin,才具有权限进行用户注册，因为该用户具有CA的全部权限，相当于CA服务的root用户。

fabric-ca-client register -d --id.name peer1-org1 --id.secret peer1PW --id.type peer -u https://0.0.0.0:7052 --tls.certfiles /root/hyperledger/fabric-ca-tls/crypto/ca-cert.pem

fabric-ca-client register -d --id.name peer2-org1 --id.secret peer2PW --id.type peer -u https://0.0.0.0:7052 --tls.certfiles /root/hyperledger/fabric-ca-tls/crypto/ca-cert.pem

fabric-ca-client register -d --id.name peer1-org2 --id.secret peer1PW --id.type peer -u https://0.0.0.0:7052 --tls.certfiles /root/hyperledger/fabric-ca-tls/crypto/ca-cert.pem

fabric-ca-client register -d --id.name peer2-org2 --id.secret peer2PW --id.type peer -u https://0.0.0.0:7052 --tls.certfiles /root/hyperledger/fabric-ca-tls/crypto/ca-cert.pem

fabric-ca-client register -d --id.name orderer1-org0 --id.secret ordererPW --id.type orderer -u https://0.0.0.0:7052 --tls.certfiles /root/hyperledger/fabric-ca-tls/crypto/ca-cert.pem

fabric-ca-client register -d --id.name admin-org1 --id.secret org1AdminPW --id.type admin -u https://0.0.0.0:7052 --tls.certfiles /root/hyperledger/fabric-ca-tls/crypto/ca-cert.pem

fabric-ca-client register -d --id.name admin-org2 --id.secret org2AdminPW --id.type admin -u https://0.0.0.0:7052 --tls.certfiles /root/hyperledger/fabric-ca-tls/crypto/ca-cert.pem

这里我们为各个节点注册TLS证书，之后Fabric网络的通信则需要通过这一步骤注册过的用户的TLS证书来进行TLS加密通信。
到这里我们只是注册了各个节点的身份，还没有获取到他们的证书。证书可以通过登录获取，不过暂时不着急获取他们的TLS证书。
接下来，我们对其他几个CA服务器进行配置。

1.2 配置Org0的CA服务

再强调一下，本文中的几个CA服务器都是根服务器，彼此之间没有任何关系，所以上一步骤的TLS CA服务器在这一部分并没有用到。

同样，本文使用Docker容器启动CA服务器。

mkdir -p /root/hyperledger/org0/ca

mkdir -p /root/hyperledger/docker-compose/org0/ca && cd /root/hyperledger/docker-compose/org0/ca

gedit docker-compose.yaml

version: '2'

networks:
  fabric-ca:

services:

  org0:
    container_name: org0
    image: hyperledger/fabric-ca:latest
    command: sh -c 'fabric-ca-server start -d -b org0-admin:org0-adminpw --port 7053'
    environment:
      - FABRIC_CA_SERVER_HOME=/root/hyperledger/fabric-ca/crypto
      - FABRIC_CA_SERVER_TLS_ENABLED=true
      - FABRIC_CA_SERVER_CSR_CN=org0
      - FABRIC_CA_SERVER_CSR_HOSTS=0.0.0.0
      - FABRIC_CA_SERVER_PORT=7053
      - FABRIC_CA_SERVER_DEBUG=true
    volumes:
      - /root/hyperledger/org0/ca:/root/hyperledger/fabric-ca  ##重要！！！记得修改这里的路径为自己的工作目录
    networks:
      - fabric-ca
    ports:
      - 7053:7053

启动容器

docker-compose up -d

注册org0的用户
设置环境变量&登陆

export FABRIC_CA_CLIENT_TLS_CERTFILES=/root/hyperledger/org0/ca/crypto/ca-cert.pem

export FABRIC_CA_CLIENT_HOME=/root/hyperledger/org0/ca/admin

fabric-ca-client enroll -d -u https://org0-admin:org0-adminpw@0.0.0.0:7053 --tls.certfiles /root/hyperledger/org0/ca/crypto/ca-cert.pem

在本组织中共有两个用户：orderer节点和admin用户(这里的admin和管理员是不同的。

将他们注册到org0的CA服务器。

fabric-ca-client register -d --id.name orderer1-org0 --id.secret ordererpw --id.type orderer -u https://0.0.0.0:7053 --tls.certfiles /root/hyperledger/org0/ca/crypto/ca-cert.pem

fabric-ca-client register -d --id.name admin-org0 --id.secret org0adminpw --id.type admin --id.attrs "hf.Registrar.Roles=client,hf.Registrar.Attributes=*,hf.Revoker=true,hf.GenCRL=true,admin=true:ecert,abac.init=true:ecert" -u https://0.0.0.0:7053 --tls.certfiles /root/hyperledger/org0/ca/crypto/ca-cert.pem

命令执行完之后，将会注册一个Orderer节点的身份和一个Admin的身份。同时在工作目录下的org0子文件夹中会有两个文件夹：crypto和admin。crypto中是CA服务器的配置信息，admin是服务器管理员的身份信息。

1.3 配置Org1的CA服务

mkdir -p /root/hyperledger/org1/ca

mkdir -p /root/hyperledger/docker-compose/org1/ca && cd /root/hyperledger/docker-compose/org1/ca

gedit docker-compose.yaml

version: '2'

networks:
  fabric-ca:

services:

  org1:
    container_name: org1
    image: hyperledger/fabric-ca:latest
    command: sh -c 'fabric-ca-server start -d -b org1-admin:org1-adminpw --port 7054'
    environment:
      - FABRIC_CA_SERVER_HOME=/root/hyperledger/fabric-ca/crypto
      - FABRIC_CA_SERVER_TLS_ENABLED=true
      - FABRIC_CA_SERVER_CSR_CN=org1
      - FABRIC_CA_SERVER_CSR_HOSTS=0.0.0.0
      - FABRIC_CA_SERVER_PORT=7054
      - FABRIC_CA_SERVER_DEBUG=true
    volumes:
      - /root/hyperledger/org1/ca:/root/hyperledger/fabric-ca  ##重要！！！记得修改这里的路径为自己的工作目录
    networks:
      - fabric-ca
    ports:
      - 7054:7054

启动容器

docker-compose up -d

注册org1的用户
设置环境变量&登陆

export FABRIC_CA_CLIENT_TLS_CERTFILES=/root/hyperledger/org1/ca/crypto/ca-cert.pem

export FABRIC_CA_CLIENT_HOME=/root/hyperledger/org1/ca/admin

fabric-ca-client enroll -d -u https://org1-admin:org1-adminpw@0.0.0.0:7054 --tls.certfiles /root/hyperledger/org1/ca/crypto/ca-cert.pem

组织一种共有四个用户：peer1,peer2,admin,user,分别注册他们

fabric-ca-client register -d --id.name peer1-org1 --id.secret peer1PW --id.type peer -u https://0.0.0.0:7054 --tls.certfiles /root/hyperledger/org1/ca/crypto/ca-cert.pem

fabric-ca-client register -d --id.name peer2-org1 --id.secret peer2PW --id.type peer -u https://0.0.0.0:7054 --tls.certfiles /root/hyperledger/org1/ca/crypto/ca-cert.pem

fabric-ca-client register -d --id.name admin-org1 --id.secret org1AdminPW --id.type admin -u https://0.0.0.0:7054 --tls.certfiles /root/hyperledger/org1/ca/crypto/ca-cert.pem

fabric-ca-client register -d --id.name user-org1 --id.secret org1UserPW --id.type client -u https://0.0.0.0:7054 --tls.certfiles /root/hyperledger/org1/ca/crypto/ca-cert.pem

1.4 配置Org2的CA服务

mkdir -p /root/hyperledger/org2/ca

mkdir -p /root/hyperledger/docker-compose/org2/ca && cd /root/hyperledger/docker-compose/org2/ca

gedit docker-compose.yaml

并在文件内添加以下内容(tips:内容格式不要乱掉)：

version: '2'

networks:
  fabric-ca:

services:

  org2:
    container_name: org2
    image: hyperledger/fabric-ca:latest
    command: sh -c 'fabric-ca-server start -d -b org2-admin:org2-adminpw --port 7055'
    environment:
      - FABRIC_CA_SERVER_HOME=/root/hyperledger/fabric-ca/crypto
      - FABRIC_CA_SERVER_TLS_ENABLED=true
      - FABRIC_CA_SERVER_CSR_CN=org2
      - FABRIC_CA_SERVER_CSR_HOSTS=0.0.0.0
      - FABRIC_CA_SERVER_PORT=7055
      - FABRIC_CA_SERVER_DEBUG=true
    volumes:
      - /root/hyperledger/org2/ca:/root/hyperledger/fabric-ca  ##重要！！！记得修改这里的路径为自己的工作目录
    networks:
      - fabric-ca
    ports:
      - 7055:7055

启动容器

docker-compose up -d

注册org1的用户
设置环境变量&登陆

export FABRIC_CA_CLIENT_TLS_CERTFILES=/root/hyperledger/org2/ca/crypto/ca-cert.pem

export FABRIC_CA_CLIENT_HOME=/root/hyperledger/org2/ca/admin

fabric-ca-client enroll -d -u https://org2-admin:org2-adminpw@0.0.0.0:7055 --tls.certfiles /root/hyperledger/org2/ca/crypto/ca-cert.pem

组织一种共有四个用户：peer1,peer2,admin,user,分别注册他们

fabric-ca-client register -d --id.name peer1-org2 --id.secret peer1PW --id.type peer -u https://0.0.0.0:7055 --tls.certfiles /root/hyperledger/org2/ca/crypto/ca-cert.pem

fabric-ca-client register -d --id.name peer2-org2 --id.secret peer2PW --id.type peer -u https://0.0.0.0:7055 --tls.certfiles /root/hyperledger/org2/ca/crypto/ca-cert.pem

fabric-ca-client register -d --id.name admin-org2 --id.secret org2AdminPW --id.type admin -u https://0.0.0.0:7055 --tls.certfiles /root/hyperledger/org2/ca/crypto/ca-cert.pem

fabric-ca-client register -d --id.name user-org2 --id.secret org2UserPW --id.type client -u https://0.0.0.0:7055 --tls.certfiles /root/hyperledger/org2/ca/crypto/ca-cert.pem

二、Org1节点配置

2.1 peer1

mkdir -p /root/hyperledger/org1/peer1/assets/ca/

cp /root/hyperledger/org1/ca/crypto/ca-cert.pem /root/hyperledger/org1/peer1/assets/ca/org1-ca-cert.pem

首先是本组织的MSP证书：
配置环境变量

export FABRIC_CA_CLIENT_HOME=/root/hyperledger/org1/peer1
export FABRIC_CA_CLIENT_TLS_CERTFILES=/root/hyperledger/org1/peer1/assets/ca/org1-ca-cert.pem
export FABRIC_CA_CLIENT_MSPDIR=msp

登陆peer1节点到org1 CA 服务器上

fabric-ca-client enroll -d -u https://peer1-org1:peer1PW@0.0.0.0:7054 --tls.certfiles /root/hyperledger/org1/ca/crypto/ca-cert.pem

这一步完成后在/root/hyperledger/org1/peer1下出现一个msp文件夹，这是peer1节点的msp证书。

接下来是TLS证书

mkdir -p /root/hyperledger/org1/peer1/assets/tls-ca
cp /root/hyperledger/fabric-ca-tls/crypto/ca-cert.pem  /root/hyperledger/org1/peer1/assets/tls-ca/tls-ca-cert.pem

配置环境变量

export FABRIC_CA_CLIENT_MSPDIR=tls-msp

export FABRIC_CA_CLIENT_TLS_CERTFILES=/root/hyperledger/org1/peer1/assets/tls-ca/tls-ca-cert.pem

登录peer1节点的TLS CA服务器上

fabric-ca-client enroll -d -u https://peer1-org1:peer1PW@0.0.0.0:7052 --enrollment.profile tls --csr.hosts peer1-org1 --tls.certfiles /root/hyperledger/org1/peer1/assets/tls-ca/tls-ca-cert.pem

这一步完成后，在/root/hyperledger/org1/peer1下会出现一个tls-msp文件夹，这是peer1节点的TLS证书。

修改秘钥文件名
为什么要修改呢，进入这个文件夹看一下就知道了,由服务器生成的秘钥文件名是一长串无规则的字符串，后期我们使用的时候难道要一个字符一个字符地输入？

mv /root/hyperledger/org1/peer1/tls-msp/keystore/*_sk /root/hyperledger/org1/peer1/tls-msp/keystore/key.pem

2.2 peer2

mkdir -p /root/hyperledger/org1/peer2/assets/ca/

cp /root/hyperledger/org1/ca/crypto/ca-cert.pem /root/hyperledger/org1/peer2/assets/ca/org1-ca-cert.pem

首先是本组织的MSP证书：
配置环境变量

export FABRIC_CA_CLIENT_HOME=/root/hyperledger/org1/peer2
export FABRIC_CA_CLIENT_TLS_CERTFILES=/root/hyperledger/org1/peer2/assets/ca/org1-ca-cert.pem
export FABRIC_CA_CLIENT_MSPDIR=msp

登陆peer1节点到org1 CA 服务器上

fabric-ca-client enroll -d -u https://peer2-org1:peer2PW@0.0.0.0:7054 --tls.certfiles /root/hyperledger/org1/ca/crypto/ca-cert.pem

这一步完成后在/root/hyperledger/org1/peer2下出现一个msp文件夹，这是peer2节点的msp证书。

接下来是TLS证书

mkdir -p /root/hyperledger/org1/peer2/assets/tls-ca/
cp /root/hyperledger/fabric-ca-tls/crypto/ca-cert.pem  /root/hyperledger/org1/peer2/assets/tls-ca/tls-ca-cert.pem

配置环境变量

export FABRIC_CA_CLIENT_MSPDIR=tls-msp
export FABRIC_CA_CLIENT_TLS_CERTFILES=/root/hyperledger/org1/peer2/assets/tls-ca/tls-ca-cert.pem

登录peer2节点的TLS CA服务器上

fabric-ca-client enroll -d -u https://peer2-org1:peer2PW@0.0.0.0:7052 --enrollment.profile tls --csr.hosts peer2-org1 --tls.certfiles /root/hyperledger/org1/peer2/assets/tls-ca/tls-ca-cert.pem

这一步完成后，在/root/hyperledger/org1/peer2下会出现一个tls-msp文件夹，这是peer2节点的TLS证书。

修改秘钥文件名
为什么要修改呢，进入这个文件夹看一下就知道了,由服务器生成的秘钥文件名是一长串无规则的字符串，后期我们使用的时候难道要一个字符一个字符地输入？

mv /root/hyperledger/org1/peer2/tls-msp/keystore/*_sk /root/hyperledger/org1/peer2/tls-msp/keystore/key.pem

2.3 admin

首先是本组织的MSP证书：
配置环境变量

export FABRIC_CA_CLIENT_HOME=/root/hyperledger/org1/admin
export FABRIC_CA_CLIENT_TLS_CERTFILES=/root/hyperledger/org1/peer1/assets/ca/org1-ca-cert.pem
export FABRIC_CA_CLIENT_MSPDIR=msp

登录admin节点的org1 CA 服务器上

fabric-ca-client enroll -d -u https://admin-org1:org1AdminPW@0.0.0.0:7054 --tls.certfiles /root/hyperledger/org1/peer1/assets/ca/org1-ca-cert.pem

接下来是TLS证书
配置环境变量

export FABRIC_CA_CLIENT_MSPDIR=tls-msp
export FABRIC_CA_CLIENT_TLS_CERTFILES=/root/hyperledger/org1/peer1/assets/tls-ca/tls-ca-cert.pem

登录admin节点的TLS CA服务器上

fabric-ca-client enroll -d -u https://admin-org1:org1AdminPW@0.0.0.0:7052 --enrollment.profile tls --csr.hosts admin-org1 --tls.certfiles /root/hyperledger/org1/peer1/assets/tls-ca/tls-ca-cert.pem

复制证书到admincerts文件夹:
去看Fabric官方的例子，每一个peer节点的MSP文件夹下都有admincerts这个子文件夹的，而且是需要我们手动创建的。

mkdir /root/hyperledger/org1/peer1/msp/admincerts
cp /root/hyperledger/org1/admin/msp/signcerts/cert.pem /root/hyperledger/org1/peer1/msp/admincerts/org1-admin-cert.pem


mkdir /root/hyperledger/org1/peer2/msp/admincerts
cp /root/hyperledger/org1/admin/msp/signcerts/cert.pem /root/hyperledger/org1/peer2/msp/admincerts/org1-admin-cert.pem

2.4启动peer节点

到这里，已经配置好了一个节点，所以我们就可以启动这个节点了，当然在之后和orderer节点一起启动也可以，不过忙活了这么多，还是应该提前看到一下所做的工作的成果的！
附上peer1节点的容器配置信息：

peer1节点配置启动

mkdir -p /root/hyperledger/docker-compose/org1/peer1 && cd /root/hyperledger/docker-compose/org1/peer1
gedit docker-compose.yaml

并在文件内添加以下内容(tips:内容格式不要乱掉)：

version: '2'

networks:
  fabric-ca:

services:
  peer1-org1:
    container_name: peer1-org1
    image: hyperledger/fabric-peer:2.3.2
    environment:
      - CORE_PEER_ID=peer1-org1
      - CORE_PEER_ADDRESS=peer1-org1:7051
      - CORE_PEER_LISTENADDRESS=0.0.0.0:7051
      - CORE_PEER_CHAINCODEADDRESS=peer1-org1:7052
      - CORE_PEER_CHAINCODELISTENADDRESS=0.0.0.0:7052
      - CORE_PEER_GOSSIP_BOOTSTRAP=peer1-org1:7051
      - CORE_PEER_GOSSIP_EXTERNALENDPOINT=peer1-org1:7051
      - CORE_PEER_LOCALMSPID=org1MSP
      - CORE_PEER_MSPCONFIGPATH=/root/hyperledger/org1/peer1/msp
      - CORE_VM_ENDPOINT=unix:///host/var/run/docker.sock
      - CORE_VM_DOCKER_HOSTCONFIG_NETWORKMODE=${COMPOSE_PROJECT_NAME}_fabric-ca
      - FABRIC_LOGGING_SPEC=debug
      - CORE_PEER_TLS_ENABLED=true
      - CORE_PEER_TLS_CERT_FILE=/root/hyperledger/org1/peer1/tls-msp/signcerts/cert.pem
      - CORE_PEER_TLS_KEY_FILE=/root/hyperledger/org1/peer1/tls-msp/keystore/key.pem
      - CORE_PEER_TLS_ROOTCERT_FILE=/root/hyperledger/org1/peer1/tls-msp/tlscacerts/tls-0-0-0-0-7052.pem
      - CORE_PEER_GOSSIP_USELEADERELECTION=true
      - CORE_PEER_GOSSIP_ORGLEADER=false
      - CORE_PEER_PROFILE_ENABLED=true
      - CORE_PEER_GOSSIP_SKIPHANDSHAKE=true
    working_dir: /opt/gopath/src/github.com/hyperledger/fabric/org1/peer1
    volumes:
      - /var/run:/host/var/run
      - /root/hyperledger/org1/peer1:/root/hyperledger/org1/peer1
    networks:
      - fabric-ca

启动容器

docker-compose up -d

如果没有报错的话，说明之前配置的没有什么问题，如果出错的话，则需要返回去检查一下了

peer2 节点配置启动

mkdir -p /root/hyperledger/docker-compose/org1/peer2 && cd /root/hyperledger/docker-compose/org1/peer2
gedit docker-compose.yaml

并在文件内添加以下内容(tips:内容格式不要乱掉)：

version: '2'

networks:
  fabric-ca:

services:
  peer2-org1:
    container_name: peer2-org1
    image: hyperledger/fabric-peer:2.3.2
    environment:
      - CORE_PEER_ID=peer2-org1
      - CORE_PEER_ADDRESS=peer2-org1:7051
      - CORE_PEER_LISTENADDRESS=0.0.0.0:7051
      - CORE_PEER_CHAINCODEADDRESS=peer2-org1:7052
      - CORE_PEER_CHAINCODELISTENADDRESS=0.0.0.0:7052
      - CORE_PEER_GOSSIP_BOOTSTRAP=peer1-org1:7051
      - CORE_PEER_GOSSIP_EXTERNALENDPOINT=peer2-org1:7051
      - CORE_PEER_LOCALMSPID=org1MSP
      - CORE_PEER_MSPCONFIGPATH=/root/hyperledger/org1/peer2/msp
      - CORE_VM_ENDPOINT=unix:///host/var/run/docker.sock
      - CORE_VM_DOCKER_HOSTCONFIG_NETWORKMODE=${COMPOSE_PROJECT_NAME}_fabric-ca
      - FABRIC_LOGGING_SPEC=debug
      - CORE_PEER_TLS_ENABLED=true
      - CORE_PEER_TLS_CERT_FILE=/root/hyperledger/org1/peer2/tls-msp/signcerts/cert.pem
      - CORE_PEER_TLS_KEY_FILE=/root/hyperledger/org1/peer2/tls-msp/keystore/key.pem
      - CORE_PEER_TLS_ROOTCERT_FILE=/root/hyperledger/org1/peer2/tls-msp/tlscacerts/tls-0-0-0-0-7052.pem
      - CORE_PEER_GOSSIP_USELEADERELECTION=true
      - CORE_PEER_GOSSIP_ORGLEADER=false
      - CORE_PEER_PROFILE_ENABLED=true
      - CORE_PEER_GOSSIP_SKIPHANDSHAKE=true
    working_dir: /opt/gopath/src/github.com/hyperledger/fabric/org1/peer2
    volumes:
      - /var/run:/host/var/run
      - /root/hyperledger/org1/peer2:/root/hyperledger/org1/peer2
    networks:
      - fabric-ca

启动容器

docker-compose up -d

三、Org2节点配置

和组织一配置一样，这里就不做过多的解释了，直接上命令

3.1 peer1

mkdir -p /root/hyperledger/org2/peer1/assets/ca
cp /root/hyperledger/org2/ca/crypto/ca-cert.pem /root/hyperledger/org2/peer1/assets/ca/org2-ca-cert.pem

配置环境变量

export FABRIC_CA_CLIENT_HOME=/root/hyperledger/org2/peer1
export FABRIC_CA_CLIENT_TLS_CERTFILES=/root/hyperledger/org2/peer1/assets/ca/org2-ca-cert.pem
export FABRIC_CA_CLIENT_MSPDIR=msp

登陆peer1节点到org2 CA服务器上

fabric-ca-client enroll -d -u https://peer1-org2:peer1PW@0.0.0.0:7055 --tls.certfiles /root/hyperledger/org2/peer1/assets/ca/org2-ca-cert.pem

接下来是TLS

mkdir /root/hyperledger/org2/peer1/assets/tls-ca
cp /root/hyperledger/fabric-ca-tls/crypto/ca-cert.pem  /root/hyperledger/org2/peer1/assets/tls-ca/tls-ca-cert.pem

配置环境变量

export FABRIC_CA_CLIENT_MSPDIR=tls-msp
export FABRIC_CA_CLIENT_TLS_CERTFILES=/root/hyperledger/org2/peer1/assets/tls-ca/tls-ca-cert.pem

登录peer1节点到 TLS CA服务器上

fabric-ca-client enroll -d -u https://peer1-org2:peer1PW@0.0.0.0:7052 --enrollment.profile tls --csr.hosts peer1-org2 --tls.certfiles /root/hyperledger/org2/peer1/assets/tls-ca/tls-ca-cert.pem

修改密钥文件

mv /root/hyperledger/org2/peer1/tls-msp/keystore/*_sk /root/hyperledger/org2/peer1/tls-msp/keystore/key.pem

3.2 peer2

mkdir -p /root/hyperledger/org2/peer2/assets/ca
cp /root/hyperledger/org2/ca/crypto/ca-cert.pem /root/hyperledger/org2/peer2/assets/ca/org2-ca-cert.pem

配置环境变量

export FABRIC_CA_CLIENT_HOME=/root/hyperledger/org2/peer2
export FABRIC_CA_CLIENT_TLS_CERTFILES=/root/hyperledger/org2/peer2/assets/ca/org2-ca-cert.pem
export FABRIC_CA_CLIENT_MSPDIR=msp

登陆peer2节点到org2 CA服务器上

fabric-ca-client enroll -d -u https://peer2-org2:peer2PW@0.0.0.0:7055 --tls.certfiles /root/hyperledger/org2/peer2/assets/ca/org2-ca-cert.pem

接下来是TLS

mkdir /root/hyperledger/org2/peer2/assets/tls-ca
cp /root/hyperledger/fabric-ca-tls/crypto/ca-cert.pem  /root/hyperledger/org2/peer2/assets/tls-ca/tls-ca-cert.pem

配置环境变量

export FABRIC_CA_CLIENT_MSPDIR=tls-msp
export FABRIC_CA_CLIENT_TLS_CERTFILES=/root/hyperledger/org2/peer2/assets/tls-ca/tls-ca-cert.pem

登录peer2节点到 TLS CA服务器上

fabric-ca-client enroll -d -u https://peer2-org2:peer2PW@0.0.0.0:7052 --enrollment.profile tls --csr.hosts peer2-org2 --tls.certfiles /root/hyperledger/org2/peer2/assets/tls-ca/tls-ca-cert.pem

修改密钥文件

mv /root/hyperledger/org2/peer2/tls-msp/keystore/*_sk /root/hyperledger/org2/peer2/tls-msp/keystore/key.pem

3.3 admin

配置环境变量

export FABRIC_CA_CLIENT_HOME=/root/hyperledger/org2/admin
export FABRIC_CA_CLIENT_TLS_CERTFILES=/root/hyperledger/org2/peer1/assets/ca/org2-ca-cert.pem
export FABRIC_CA_CLIENT_MSPDIR=msp

登陆admin节点到org2 CA服务器上

fabric-ca-client enroll -d -u https://admin-org2:org2AdminPW@0.0.0.0:7055 --tls.certfiles /root/hyperledger/org2/peer1/assets/ca/org2-ca-cert.pem

接下来是TLS

配置环境变量

export FABRIC_CA_CLIENT_MSPDIR=tls-msp
export FABRIC_CA_CLIENT_TLS_CERTFILES=/root/hyperledger/org2/peer1/assets/tls-ca/tls-ca-cert.pem

登录admin节点到 TLS CA服务器上

fabric-ca-client enroll -d -u https://admin-org2:org2AdminPW@0.0.0.0:7052 --enrollment.profile tls --csr.hosts admin-org2 --tls.certfiles /root/hyperledger/org2/peer1/assets/tls-ca/tls-ca-cert.pem

3.4 复制证书到admincerts文件夹:

mkdir /root/hyperledger/org2/peer1/msp/admincerts
cp /root/hyperledger/org2/admin/msp/signcerts/cert.pem /root/hyperledger/org2/peer1/msp/admincerts/org2-admin-cert.pem


mkdir /root/hyperledger/org2/peer2/msp/admincerts
cp /root/hyperledger/org2/admin/msp/signcerts/cert.pem /root/hyperledger/org2/peer2/msp/admincerts/org2-admin-cert.pem

3.5 启动peer节点

peer1节点配置

mkdir -p /root/hyperledger/docker-compose/org2/peer1 && cd /root/hyperledger/docker-compose/org2/peer1
gedit docker-compose.yaml

并在文件内添加以下内容(tips:内容格式不要乱掉)：

version: '2'

networks:
  fabric-ca:

services:
  peer1-org2:
    container_name: peer1-org2
    image: hyperledger/fabric-peer:2.3.2
    environment:
      - CORE_PEER_ID=peer1-org2
      - CORE_PEER_ADDRESS=peer1-org2:7051
      - CORE_PEER_LISTENADDRESS=0.0.0.0:7051
      - CORE_PEER_CHAINCODEADDRESS=peer1-org2:7052
      - CORE_PEER_CHAINCODELISTENADDRESS=0.0.0.0:7052
      - CORE_PEER_GOSSIP_BOOTSTRAP=peer1-org2:7051
      - CORE_PEER_GOSSIP_EXTERNALENDPOINT=peer1-org2:7051
      - CORE_PEER_LOCALMSPID=org2MSP
      - CORE_PEER_MSPCONFIGPATH=/root/hyperledger/org2/peer1/msp
      - CORE_VM_ENDPOINT=unix:///host/var/run/docker.sock
      - CORE_VM_DOCKER_HOSTCONFIG_NETWORKMODE=${COMPOSE_PROJECT_NAME}_fabric-ca
      - FABRIC_LOGGING_SPEC=debug
      - CORE_PEER_TLS_ENABLED=true
      - CORE_PEER_TLS_CERT_FILE=/root/hyperledger/org2/peer1/tls-msp/signcerts/cert.pem
      - CORE_PEER_TLS_KEY_FILE=/root/hyperledger/org2/peer1/tls-msp/keystore/key.pem
      - CORE_PEER_TLS_ROOTCERT_FILE=/root/hyperledger/org2/peer1/tls-msp/tlscacerts/tls-0-0-0-0-7052.pem
      - CORE_PEER_GOSSIP_USELEADERELECTION=true
      - CORE_PEER_GOSSIP_ORGLEADER=false
      - CORE_PEER_PROFILE_ENABLED=true
      - CORE_PEER_GOSSIP_SKIPHANDSHAKE=true
    working_dir: /opt/gopath/src/github.com/hyperledger/fabric/org2/peer1
    volumes:
      - /var/run:/host/var/run
      - /root/hyperledger/org2/peer1:/root/hyperledger/org2/peer1
    networks:
      - fabric-ca

启动容器

docker-compose up -d

peer2节点配置

mkdir -p /root/hyperledger/docker-compose/org2/peer2 && cd /root/hyperledger/docker-compose/org2/peer2
gedit docker-compose.yaml

并在文件内添加以下内容(tips:内容格式不要乱掉)：

version: '2'

networks:
  fabric-ca:

services:
  peer2-org2:
    container_name: peer2-org2
    image: hyperledger/fabric-peer:2.3.2
    environment:
      - CORE_PEER_ID=peer2-org2
      - CORE_PEER_ADDRESS=peer2-org2:7051
      - CORE_PEER_LISTENADDRESS=0.0.0.0:7051
      - CORE_PEER_CHAINCODEADDRESS=peer2-org2:7052
      - CORE_PEER_CHAINCODELISTENADDRESS=0.0.0.0:7052
      - CORE_PEER_GOSSIP_BOOTSTRAP=peer1-org2:7051
      - CORE_PEER_GOSSIP_EXTERNALENDPOINT=peer2-org2:7051
      - CORE_PEER_LOCALMSPID=org2MSP
      - CORE_PEER_MSPCONFIGPATH=/root/hyperledger/org2/peer2/msp
      - CORE_VM_ENDPOINT=unix:///host/var/run/docker.sock
      - CORE_VM_DOCKER_HOSTCONFIG_NETWORKMODE=${COMPOSE_PROJECT_NAME}_fabric-ca
      - FABRIC_LOGGING_SPEC=debug
      - CORE_PEER_TLS_ENABLED=true
      - CORE_PEER_TLS_CERT_FILE=/root/hyperledger/org2/peer2/tls-msp/signcerts/cert.pem
      - CORE_PEER_TLS_KEY_FILE=/root/hyperledger/org2/peer2/tls-msp/keystore/key.pem
      - CORE_PEER_TLS_ROOTCERT_FILE=/root/hyperledger/org2/peer2/tls-msp/tlscacerts/tls-0-0-0-0-7052.pem
      - CORE_PEER_GOSSIP_USELEADERELECTION=true
      - CORE_PEER_GOSSIP_ORGLEADER=false
      - CORE_PEER_GOSSIP_SKIPHANDSHAKE=true
      - CORE_PEER_PROFILE_ENABLED=true
    working_dir: /opt/gopath/src/github.com/hyperledger/fabric/org2/peer2
    volumes:
      - /var/run:/host/var/run
      - /root/hyperledger/org2/peer2:/root/hyperledger/org2/peer2
    networks:
      - fabric-ca

启动容器

docker-compose up -d

四、 排序节点配置

接下来是排序节点的配置，为什么放在最后面呢，因为排序节点的启动需要提前生成创世区块，而创世区块的生成涉及到另一个配置文件，所以就先配置简单的peer节点

4.1 orderer

mkdir -p /root/hyperledger/org0/orderer/assets/ca/
cp /root/hyperledger/org0/ca/crypto/ca-cert.pem /root/hyperledger/org0/orderer/assets/ca/org0-ca-cert.pem

配置环境变量

export FABRIC_CA_CLIENT_HOME=/root/hyperledger/org0/orderer
export FABRIC_CA_CLIENT_TLS_CERTFILES=/root/hyperledger/org0/orderer/assets/ca/org0-ca-cert.pem
export FABRIC_CA_CLIENT_MSPDIR=msp

登录order节点到org0 CA服务器上

fabric-ca-client enroll -d -u https://orderer1-org0:ordererpw@0.0.0.0:7053 --tls.certfiles /root/hyperledger/org0/orderer/assets/ca/org0-ca-cert.pem

接下来是TLS证书

mkdir /root/hyperledger/org0/orderer/assets/tls-ca/
cp /root/hyperledger/fabric-ca-tls/crypto/ca-cert.pem  /root/hyperledger/org0/orderer/assets/tls-ca/tls-ca-cert.pem

配置环境变量

export FABRIC_CA_CLIENT_MSPDIR=tls-msp
export FABRIC_CA_CLIENT_TLS_CERTFILES=/root/hyperledger/org0/orderer/assets/tls-ca/tls-ca-cert.pem

登录order节点到TLS CA服务器上

fabric-ca-client enroll -d -u https://orderer1-org0:ordererPW@0.0.0.0:7052 --enrollment.profile tls --csr.hosts orderer1-org0 --tls.certfiles /root/hyperledger/org0/orderer/assets/tls-ca/tls-ca-cert.pem

修改密钥

mv /root/hyperledger/org0/orderer/tls-msp/keystore/*_sk /root/hyperledger/org0/orderer/tls-msp/keystore/key.pem

4.2 admin

配置环境变量

export FABRIC_CA_CLIENT_HOME=/root/hyperledger/org0/admin
export FABRIC_CA_CLIENT_TLS_CERTFILES=/root/hyperledger/org0/orderer/assets/ca/org0-ca-cert.pem
export FABRIC_CA_CLIENT_MSPDIR=msp

登录admin 用户获取msp

fabric-ca-client enroll -d -u https://admin-org0:org0adminpw@0.0.0.0:7053 --tls.certfiles /root/hyperledger/org0/orderer/assets/ca/org0-ca-cert.pem

复制证书到admincerts文件夹:

mkdir /root/hyperledger/org0/orderer/msp/admincerts
cp /root/hyperledger/org0/admin/msp/signcerts/cert.pem /root/hyperledger/org0/orderer/msp/admincerts/orderer-admin-cert.pem

4.3 添加config.yaml

证书都准备好了之后我们还需要在每个msp文件下添加一个config.yaml

NodeOUs:
  Enable: true
  ClientOUIdentifier:
    #修改对应的证书名称
    Certificate: cacerts/0-0-0-0-7053.pem
    OrganizationalUnitIdentifier: client
  PeerOUIdentifier:
    Certificate: cacerts/0-0-0-0-7053.pem
    OrganizationalUnitIdentifier: peer
  AdminOUIdentifier:
    Certificate: cacerts/0-0-0-0-7053.pem
    OrganizationalUnitIdentifier: admin
  OrdererOUIdentifier:
    Certificate: cacerts/0-0-0-0-7053.pem
    OrganizationalUnitIdentifier: orderer

需要org0，org1, org2 下所有msp目录下都添加。

org0

cd /root/hyperledger/org0
gedit config.yaml

NodeOUs:
  Enable: true
  ClientOUIdentifier:
    #修改对应的证书名称
    Certificate: cacerts/0-0-0-0-7053.pem
    OrganizationalUnitIdentifier: client
  PeerOUIdentifier:
    Certificate: cacerts/0-0-0-0-7053.pem
    OrganizationalUnitIdentifier: peer
  AdminOUIdentifier:
    Certificate: cacerts/0-0-0-0-7053.pem
    OrganizationalUnitIdentifier: admin
  OrdererOUIdentifier:
    Certificate: cacerts/0-0-0-0-7053.pem
    OrganizationalUnitIdentifier: orderer

复制文件到所有msp目录下

find ./ -name msp -type d -exec cp -r /root/hyperledger/org0/config.yaml {} \;

查找所有的config.yaml文件

find ./ -name config.yaml -type f

org1

cd /root/hyperledger/org1
gedit config.yaml

NodeOUs:
  Enable: true
  ClientOUIdentifier:
    #修改对应的证书名称
    Certificate: cacerts/0-0-0-0-7054.pem
    OrganizationalUnitIdentifier: client
  PeerOUIdentifier:
    Certificate: cacerts/0-0-0-0-7054.pem
    OrganizationalUnitIdentifier: peer
  AdminOUIdentifier:
    Certificate: cacerts/0-0-0-0-7054.pem
    OrganizationalUnitIdentifier: admin
  OrdererOUIdentifier:
    Certificate: cacerts/0-0-0-0-7054.pem
    OrganizationalUnitIdentifier: orderer

复制文件到所有msp目录下

find ./ -name msp -type d -exec cp -r /root/hyperledger/org1/config.yaml {} \;

查找所有的config.yaml文件

find ./ -name config.yaml -type f

org2

cd /root/hyperledger/org2
gedit config.yaml

NodeOUs:
  Enable: true
  ClientOUIdentifier:
    #修改对应的证书名称
    Certificate: cacerts/0-0-0-0-7055.pem
    OrganizationalUnitIdentifier: client
  PeerOUIdentifier:
    Certificate: cacerts/0-0-0-0-7055.pem
    OrganizationalUnitIdentifier: peer
  AdminOUIdentifier:
    Certificate: cacerts/0-0-0-0-7055.pem
    OrganizationalUnitIdentifier: admin
  OrdererOUIdentifier:
    Certificate: cacerts/0-0-0-0-7055.pem
    OrganizationalUnitIdentifier: orderer

复制文件到所有msp目录下

find ./ -name msp -type d -exec cp -r /root/hyperledger/org2/config.yaml {} \;

查找所有的config.yaml文件

find ./ -name config.yaml -type f

五、Fabric 网络

证书都生成好了，即将要启动网络了。不过在启动网络之前还是有很多准备工作需要做。

5.1 整理MSPDir文件

#---------------org0--------------------
mkdir -p /root/hyperledger/configtx && cd /root/hyperledger/configtx
mkdir org0
cp -r ../org0/admin/msp org0/
cd  org0/msp
mkdir tlscacerts && cd tlscacerts
cp  /root/hyperledger/org0/orderer/tls-msp/tlscacerts/tls-0-0-0-0-7052.pem ./
#---------------org1--------------------
cd /root/hyperledger/configtx
mkdir org1
cp -r ../org1/admin/msp org1/
cd org1/msp
mkdir tlscacerts && cd tlscacerts
cp /root/hyperledger/org1/admin/tls-msp/tlscacerts/tls-0-0-0-0-7052.pem ./
#---------------org2--------------------
cd /root/hyperledger/configtx
mkdir org2
cp -r ../org2/admin/msp org2/
cd org2/msp
mkdir tlscacerts && cd tlscacerts
cp /root/hyperledger/org2/admin/tls-msp/tlscacerts/tls-0-0-0-0-7052.pem ./

5.2 configtx.yaml文件配置

在下一个步骤的生成创世区块和通道配置信息需要一个文件：configtx.yaml文件。

cd /root/hyperledger/configtx
gedit configtx.yaml

文件内容

# Copyright IBM Corp. All Rights Reserved.
#
# SPDX-License-Identifier: Apache-2.0
#

---
################################################################################
#
#   Section: Organizations
#
#   - This section defines the different organizational identities which will
#   be referenced later in the configuration.
#
################################################################################
Organizations:

    # SampleOrg defines an MSP using the sampleconfig.  It should never be used
    # in production but may be used as a template for other definitions
    - &org0
        # DefaultOrg defines the organization which is used in the sampleconfig
        # of the fabric.git development environment
        Name: org0MSP

        # ID to load the MSP definition as
        ID: org0MSP

        # MSPDir is the filesystem path which contains the MSP configuration
        MSPDir: ../configtx/org0/msp

        # Policies defines the set of policies at this level of the config tree
        # For organization policies, their canonical path is usually
        #   /Channel/<Application|Orderer>/<OrgName>/<PolicyName>
        Policies:
            Readers:
                Type: Signature
                Rule: "OR('org0MSP.member')"
            Writers:
                Type: Signature
                Rule: "OR('org0MSP.member')"
            Admins:
                Type: Signature
                Rule: "OR('org0MSP.admin')"

        OrdererEndpoints:
            - orderer1-org0:7050

    - &org1
        # DefaultOrg defines the organization which is used in the sampleconfig
        # of the fabric.git development environment
        Name: org1MSP

        # ID to load the MSP definition as
        ID: org1MSP

        MSPDir: ../configtx/org1/msp

        # Policies defines the set of policies at this level of the config tree
        # For organization policies, their canonical path is usually
        #   /Channel/<Application|Orderer>/<OrgName>/<PolicyName>
        Policies:
            Readers:
                Type: Signature
                Rule: "OR('org1MSP.admin', 'org1MSP.peer', 'org1MSP.client')"
            Writers:
                Type: Signature
                Rule: "OR('org1MSP.admin', 'org1MSP.client')"
            Admins:
                Type: Signature
                Rule: "OR('org1MSP.admin')"
            Endorsement:
                Type: Signature
                Rule: "OR('org1MSP.peer')"

        # leave this flag set to true.
        AnchorPeers:
            # AnchorPeers defines the location of peers which can be used
            # for cross org gossip communication.  Note, this value is only
            # encoded in the genesis block in the Application section context
            - Host: peer1-org1
              Port: 7051

    - &org2
        # DefaultOrg defines the organization which is used in the sampleconfig
        # of the fabric.git development environment
        Name: org2MSP

        # ID to load the MSP definition as
        ID: org2MSP

        MSPDir: ../configtx/org2/msp

        # Policies defines the set of policies at this level of the config tree
        # For organization policies, their canonical path is usually
        #   /Channel/<Application|Orderer>/<OrgName>/<PolicyName>
        Policies:
            Readers:
                Type: Signature
                Rule: "OR('org2MSP.admin', 'org2MSP.peer', 'org2MSP.client')"
            Writers:
                Type: Signature
                Rule: "OR('org2MSP.admin', 'org2MSP.client')"
            Admins:
                Type: Signature
                Rule: "OR('org2MSP.admin')"
            Endorsement:
                Type: Signature
                Rule: "OR('org2MSP.peer')"

        AnchorPeers:
            # AnchorPeers defines the location of peers which can be used
            # for cross org gossip communication.  Note, this value is only
            # encoded in the genesis block in the Application section context
            - Host: peer1-org2
              Port: 7051

################################################################################
#
#   SECTION: Capabilities
#
#   - This section defines the capabilities of fabric network. This is a new
#   concept as of v1.1.0 and should not be utilized in mixed networks with
#   v1.0.x peers and orderers.  Capabilities define features which must be
#   present in a fabric binary for that binary to safely participate in the
#   fabric network.  For instance, if a new MSP type is added, newer binaries
#   might recognize and validate the signatures from this type, while older
#   binaries without this support would be unable to validate those
#   transactions.  This could lead to different versions of the fabric binaries
#   having different world states.  Instead, defining a capability for a channel
#   informs those binaries without this capability that they must cease
#   processing transactions until they have been upgraded.  For v1.0.x if any
#   capabilities are defined (including a map with all capabilities turned off)
#   then the v1.0.x peer will deliberately crash.
#
################################################################################
Capabilities:
    # Channel capabilities apply to both the orderers and the peers and must be
    # supported by both.
    # Set the value of the capability to true to require it.
    Channel: &ChannelCapabilities
        # V2_0 capability ensures that orderers and peers behave according
        # to v2.0 channel capabilities. Orderers and peers from
        # prior releases would behave in an incompatible way, and are therefore
        # not able to participate in channels at v2.0 capability.
        # Prior to enabling V2.0 channel capabilities, ensure that all
        # orderers and peers on a channel are at v2.0.0 or later.
        V2_0: true

    # Orderer capabilities apply only to the orderers, and may be safely
    # used with prior release peers.
    # Set the value of the capability to true to require it.
    Orderer: &OrdererCapabilities
        # V2_0 orderer capability ensures that orderers behave according
        # to v2.0 orderer capabilities. Orderers from
        # prior releases would behave in an incompatible way, and are therefore
        # not able to participate in channels at v2.0 orderer capability.
        # Prior to enabling V2.0 orderer capabilities, ensure that all
        # orderers on channel are at v2.0.0 or later.
        V2_0: true

    # Application capabilities apply only to the peer network, and may be safely
    # used with prior release orderers.
    # Set the value of the capability to true to require it.
    Application: &ApplicationCapabilities
        # V2_0 application capability ensures that peers behave according
        # to v2.0 application capabilities. Peers from
        # prior releases would behave in an incompatible way, and are therefore
        # not able to participate in channels at v2.0 application capability.
        # Prior to enabling V2.0 application capabilities, ensure that all
        # peers on channel are at v2.0.0 or later.
        V2_0: true

################################################################################
#
#   SECTION: Application
#
#   - This section defines the values to encode into a config transaction or
#   genesis block for application related parameters
#
################################################################################
Application: &ApplicationDefaults

    # Organizations is the list of orgs which are defined as participants on
    # the application side of the network
    Organizations:

    # Policies defines the set of policies at this level of the config tree
    # For Application policies, their canonical path is
    #   /Channel/Application/<PolicyName>
    Policies:
        Readers:
            Type: ImplicitMeta
            Rule: "ANY Readers"
        Writers:
            Type: ImplicitMeta
            Rule: "ANY Writers"
        Admins:
            Type: ImplicitMeta
            Rule: "MAJORITY Admins"
        LifecycleEndorsement:
            Type: ImplicitMeta
            Rule: "MAJORITY Endorsement"
        Endorsement:
            Type: ImplicitMeta
            Rule: "MAJORITY Endorsement"

    Capabilities:
        <<: *ApplicationCapabilities
################################################################################
#
#   SECTION: Orderer
#
#   - This section defines the values to encode into a config transaction or
#   genesis block for orderer related parameters
#
################################################################################
Orderer: &OrdererDefaults

    # Orderer Type: The orderer implementation to start
    OrdererType: etcdraft

    EtcdRaft:
        Consenters:
        - Host: orderer1-org0
          Port: 7050
          ClientTLSCert: /root/hyperledger/org0/orderer/tls-msp/signcerts/cert.pem
          ServerTLSCert: /root/hyperledger/org0/orderer/tls-msp/signcerts/cert.pem

    # Batch Timeout: The amount of time to wait before creating a batch
    BatchTimeout: 2s

    # Batch Size: Controls the number of messages batched into a block
    BatchSize:

        # Max Message Count: The maximum number of messages to permit in a batch
        MaxMessageCount: 10

        # Absolute Max Bytes: The absolute maximum number of bytes allowed for
        # the serialized messages in a batch.
        AbsoluteMaxBytes: 99 MB

        # Preferred Max Bytes: The preferred maximum number of bytes allowed for
        # the serialized messages in a batch. A message larger than the preferred
        # max bytes will result in a batch larger than preferred max bytes.
        PreferredMaxBytes: 512 KB

    # Organizations is the list of orgs which are defined as participants on
    # the orderer side of the network
    Organizations:

    # Policies defines the set of policies at this level of the config tree
    # For Orderer policies, their canonical path is
    #   /Channel/Orderer/<PolicyName>
    Policies:
        Readers:
            Type: ImplicitMeta
            Rule: "ANY Readers"
        Writers:
            Type: ImplicitMeta
            Rule: "ANY Writers"
        Admins:
            Type: ImplicitMeta
            Rule: "MAJORITY Admins"
        # BlockValidation specifies what signatures must be included in the block
        # from the orderer for the peer to validate it.
        BlockValidation:
            Type: ImplicitMeta
            Rule: "ANY Writers"

################################################################################
#
#   CHANNEL
#
#   This section defines the values to encode into a config transaction or
#   genesis block for channel related parameters.
#
################################################################################
Channel: &ChannelDefaults
    # Policies defines the set of policies at this level of the config tree
    # For Channel policies, their canonical path is
    #   /Channel/<PolicyName>
    Policies:
        # Who may invoke the 'Deliver' API
        Readers:
            Type: ImplicitMeta
            Rule: "ANY Readers"
        # Who may invoke the 'Broadcast' API
        Writers:
            Type: ImplicitMeta
            Rule: "ANY Writers"
        # By default, who may modify elements at this config level
        Admins:
            Type: ImplicitMeta
            Rule: "MAJORITY Admins"

    # Capabilities describes the channel level capabilities, see the
    # dedicated Capabilities section elsewhere in this file for a full
    # description
    Capabilities:
        <<: *ChannelCapabilities

################################################################################
#
#   Profile
#
#   - Different configuration profiles may be encoded here to be specified
#   as parameters to the configtxgen tool
#
################################################################################
Profiles:

    TwoOrgsOrdererGenesis:
        <<: *ChannelDefaults
        Orderer:
            <<: *OrdererDefaults
            Organizations:
                - *org0
            Capabilities:
                <<: *OrdererCapabilities
        Consortiums:
            SampleConsortium:
                Organizations:
                    - *org1
                    - *org2
    TwoOrgsChannel:
        Consortium: SampleConsortium
        <<: *ChannelDefaults
        Application:
            <<: *ApplicationDefaults
            Organizations:
                - *org1
                - *org2
            Capabilities:
                <<: *ApplicationCapabilities

注：根据情况修改MSP的路径

5.3 生成创世区块和通道信息

cd /root/hyperledger/configtx
mkdir system-genesis-block
mkdir channel-artifacts

#生成创世区块文件TwoOrgsOrdererGenesis
export FABRIC_CFG_PATH=$(pwd)
configtxgen -profile TwoOrgsOrdererGenesis -channelID system-channel -outputBlock ./system-genesis-block/genesis.block

#生成通道
export CHANNEL_NAME=mychannel
configtxgen -profile TwoOrgsChannel -outputCreateChannelTx ./channel-artifacts/${CHANNEL_NAME}.tx -channelID ${CHANNEL_NAME}

#锚节点更新配置
export orgmsp=org1MSP
configtxgen -profile TwoOrgsChannel -outputAnchorPeersUpdate ./channel-artifacts/${orgmsp}anchors.tx -channelID ${CHANNEL_NAME} -asOrg ${orgmsp}

#锚节点更新配置
export orgmsp=org2MSP
configtxgen -profile TwoOrgsChannel -outputAnchorPeersUpdate ./channel-artifacts/${orgmsp}anchors.tx -channelID ${CHANNEL_NAME} -asOrg ${orgmsp}

创世区块文件通&道信息生成后启动orderer节

mkdir -p /root/hyperledger/docker-compose/org0/orderer && cd /root/hyperledger/docker-compose/org0/orderer
gedit docker-compose.yaml

并在文件内添加以下内容(tips:内容格式不要乱掉)：

version: '2'

networks:
  fabric-ca:
services:
  orderer1-org0:
    container_name: orderer1-org0
    image: hyperledger/fabric-orderer:2.3.2
    environment:
      - ORDERER_HOME=/root/hyperledger/orderer
      - ORDERER_HOST=orderer1-org0
      - ORDERER_GENERAL_LISTENADDRESS=0.0.0.0
      - ORDERER_GENERAL_LISTENPORT=7050
      - ORDERER_GENERAL_GENESISMETHOD=file
      - ORDERER_GENERAL_GENESISFILE=/root/hyperledger/orderer/orderer.genesis.block
      - ORDERER_GENERAL_LOCALMSPID=org0MSP
      - ORDERER_GENERAL_LOCALMSPDIR=/root/hyperledger/org0/orderer/msp
      - ORDERER_GENERAL_TLS_ENABLED=true

      - ORDERER_GENERAL_TLS_PRIVATEKEY=/root/hyperledger/org0/orderer/tls-msp/keystore/key.pem
      - ORDERER_GENERAL_TLS_CERTIFICATE=/root/hyperledger/org0/orderer/tls-msp/signcerts/cert.pem
      - ORDERER_GENERAL_TLS_ROOTCAS=[/root/hyperledger/org0/orderer/tls-msp/tlscacerts/tls-0-0-0-0-7052.pem]

      - ORDERER_KAFKA_TOPIC_REPLICATIONFACTOR=1
      - ORDERER_KAFKA_VERBOSE=true
      - ORDERER_GENERAL_CLUSTER_CLIENTCERTIFICATE=/root/hyperledger/org0/orderer/tls-msp/signcerts/cert.pem
      - ORDERER_GENERAL_CLUSTER_CLIENTPRIVATEKEY=/root/hyperledger/org0/orderer/tls-msp/keystore/key.pem
      - ORDERER_GENERAL_CLUSTER_ROOTCAS=[/root/hyperledger/org0/orderer/tls-msp/tlscacerts/tls-0-0-0-0-7052.pem]

      - ORDERER_GENERAL_LOGLEVEL=debug
      - ORDERER_DEBUG_BROADCASTTRACEDIR=data/logs
    volumes:
      - /root/hyperledger/org0/orderer:/root/hyperledger/org0/orderer/
      - /root/hyperledger/configtx/system-genesis-block/genesis.block:/root/hyperledger/orderer/orderer.genesis.block

    networks:
      - fabric-ca

启动容器

docker-compose up -d

5.4 启动Org1的cli

cli容器内容,我们需要这个容器对组织1进行链码的交互

mkdir -p /root/hyperledger/docker-compose/org1/cli
cd /root/hyperledger/docker-compose/org1/cli
gedit docker-compose.yaml

并在文件内添加以下内容(tips:内容格式不要乱掉)：

version: '2'

networks:
  fabric-ca:
services:
    cli-org1:
      container_name: cli-org1
      image: hyperledger/fabric-tools:2.3.2
      tty: true
      stdin_open: true
      environment:
        - SYS_CHANNEL=testchainid
        - GOPATH=/opt/gopath
        - CORE_VM_ENDPOINT=unix:///host/var/run/docker.sock
        - FABRIC_LOGGING_SPEC=DEBUG
        - CORE_PEER_ID=cli-org1
        - CORE_PEER_ADDRESS=peer1-org1:7051
        - CORE_PEER_LOCALMSPID=org1MSP
        - CORE_PEER_TLS_ENABLED=true
        - CORE_PEER_TLS_ROOTCERT_FILE=/root/hyperledger/org1/peer1/tls-msp/tlscacerts/tls-0-0-0-0-7052.pem
        - CORE_PEER_TLS_CERT_FILE=/root/hyperledger/org1/peer1/tls-msp/signcerts/cert.pem
        - CORE_PEER_TLS_KEY_FILE=/root/hyperledger/org1/peer1/tls-msp/keystore/key.pem
        - CORE_PEER_MSPCONFIGPATH=/root/hyperledger/org1/peer1/msp
      working_dir: /opt/gopath/src/github.com/hyperledger/fabric/org1
      command: /bin/bash
      volumes:
        - /root/hyperledger/org1:/root/hyperledger/org1/
        - /root/hyperledger/org2:/root/hyperledger/org2/
        - /root/hyperledger/org1/peer1/assets/chaincode:/opt/gopath/src/github.com/hyperledger/fabric-samples/chaincode
        - /root/hyperledger/org1/admin:/root/hyperledger/org1/admin
        - /root/hyperledger/org0/orderer/tls-msp/tlscacerts/tls-0-0-0-0-7052.pem:/root/hyperledger/org0/orderer/tls-msp/tlscacerts/tls-0-0-0-0-7052.pem
        - /root/hyperledger/org1/peer1/tls-msp/tlscacerts:/root/hyperledger/org1/admin/msp/tlscacerts
        - /root/hyperledger/configtx/channel-artifacts:/root/hyperledger/configtx/channel-artifacts
      networks:
        - fabric-ca

启动容器

docker-compose up -d

5.5 启动Org2的cli

cli容器内容,我们需要这个容器对组织1进行链码的交互

mkdir -p /root/hyperledger/docker-compose/org2/cli
cd /root/hyperledger/docker-compose/org2/cli
gedit docker-compose.yaml

并在文件内添加以下内容(tips:内容格式不要乱掉)：

version: '2'

networks:
  fabric-ca:
services:
    cli-org2:
      container_name: cli-org2
      image: hyperledger/fabric-tools:2.3.2
      tty: true
      stdin_open: true
      environment:
        - SYS_CHANNEL=testchainid
        - GOPATH=/opt/gopath
        - CORE_VM_ENDPOINT=unix:///host/var/run/docker.sock
        - FABRIC_LOGGING_SPEC=DEBUG
        - CORE_PEER_ID=cli-org2
        - CORE_PEER_ADDRESS=peer1-org2:7051
        - CORE_PEER_LOCALMSPID=org2MSP
        - CORE_PEER_TLS_ENABLED=true
        - CORE_PEER_TLS_ROOTCERT_FILE=/root/hyperledger/org2/peer1/tls-msp/tlscacerts/tls-0-0-0-0-7052.pem
        - CORE_PEER_TLS_CERT_FILE=/root/hyperledger/org2/peer1/tls-msp/signcerts/cert.pem
        - CORE_PEER_TLS_KEY_FILE=/root/hyperledger/org2/peer1/tls-msp/keystore/key.pem
        - CORE_PEER_MSPCONFIGPATH=/root/hyperledger/org2/peer1/msp
      working_dir: /opt/gopath/src/github.com/hyperledger/fabric/org2
      command: /bin/bash
      volumes:
        - /root/hyperledger/org1:/root/hyperledger/org1/
        - /root/hyperledger/org2:/root/hyperledger/org2/
        - /root/hyperledger/org2/peer1:/root/hyperledger/org2/peer1
        - /root/hyperledger/org2/peer1/assets/chaincode:/opt/gopath/src/github.com/hyperledger/fabric-samples/chaincode
        - /root/hyperledger/org2/admin:/root/hyperledger/org2/admin
        - /root/hyperledger/org0/orderer/tls-msp/tlscacerts/tls-0-0-0-0-7052.pem:/root/hyperledger/org0/orderer/tls-msp/tlscacerts/tls-0-0-0-0-7052.pem
        - /root/hyperledger/org2/peer1/tls-msp/tlscacerts:/root/hyperledger/org2/peer1/msp/tlscacerts
        - /root/hyperledger/configtx/channel-artifacts:/root/hyperledger/configtx/channel-artifacts
      networks:
        - fabric-ca

启动容器

docker-compose up -d

六、创建&加入通道

6.1 操作容器cli-org1

#进入容器cli-org1进行操作
docker exec -it cli-org1 bash

export CHANNEL_NAME=mychannel
export ORDERER_CA=/root/hyperledger/org0/orderer/tls-msp/tlscacerts/tls-0-0-0-0-7052.pem
export CORE_PEER_MSPCONFIGPATH=/root/hyperledger/org1/admin/msp

cd /root/hyperledger/configtx

#不行的话就重启，然后运行/root/hyperledger/docker-compose/down.sh文件
#然后再启动start.sh文件
#创建通道
peer channel create -o orderer1-org0:7050 -c ${CHANNEL_NAME} --ordererTLSHostnameOverride orderer1-org0 -f ./channel-artifacts/${CHANNEL_NAME}.tx --outputBlock ./channel-artifacts/${CHANNEL_NAME}.block --tls true --cafile ${ORDERER_CA}

#peer1-org1加入通道
export CORE_PEER_ADDRESS=peer1-org1:7051
peer channel join -b ./channel-artifacts/mychannel.block
#peer2-org1加入通道
export CORE_PEER_ADDRESS=peer2-org1:7051
peer channel join -b ./channel-artifacts/mychannel.block

#更新锚点
export CORE_PEER_LOCALMSPID=org1MSP
peer channel update -o orderer1-org0:7050 --ordererTLSHostnameOverride orderer1-org0 -c $CHANNEL_NAME -f ./channel-artifacts/${CORE_PEER_LOCALMSPID}anchors.tx --tls --cafile $ORDERER_CA

#退出容器
exit

6.2 操作容器cli-org2

#进入容器cli-org2进行操作
docker exec -it cli-org2 bash
cd /root/hyperledger/configtx

#peer1-org2加入通道
export CORE_PEER_MSPCONFIGPATH=/root/hyperledger/org2/admin/msp
export CORE_PEER_ADDRESS=peer1-org2:7051
peer channel join -b ./channel-artifacts/mychannel.block

#peer2-org2加入通道
export CORE_PEER_ADDRESS=peer2-org2:7051
peer channel join -b ./channel-artifacts/mychannel.block

#更新锚点
export CHANNEL_NAME=mychannel
export ORDERER_CA=/root/hyperledger/org0/orderer/tls-msp/tlscacerts/tls-0-0-0-0-7052.pem
export CORE_PEER_LOCALMSPID=org2MSP

peer channel update -o orderer1-org0:7050 --ordererTLSHostnameOverride orderer1-org0 -c $CHANNEL_NAME -f ./channel-artifacts/${CORE_PEER_LOCALMSPID}anchors.tx --tls --cafile $ORDERER_CA

#退出容器
exit

七、链码安装测试

#拷贝文件到目录下
docker cp /root/go/src/github.com/hyperledger/fabric/scripts/fabric-samples/chaincode/fabcar/javascript cli-org1:/root
#进行打包安装

peer lifecycle chaincode package fabcar.tar.gz --path /root/javascript/ --lang node --label fabcar_1

#然后拷贝到root目录下
docker cp cli-org1:/root/fabcar.tar.gz /root

7.1 链码安装

cli-org1安装

#之后只用拷贝到文件里去就行了
docker cp /root/fabcar.tar.gz cli-org1:/root/hyperledger/org1/peer1/assets/chaincode
#进入cli-org1
docker exec -it cli-org1 bash

cd /root/hyperledger/org1/peer1/assets/chaincode
export CORE_PEER_ADDRESS=peer1-org1:7051
export CORE_PEER_MSPCONFIGPATH=/root/hyperledger/org1/admin/msp
peer lifecycle chaincode install fabcar.tar.gz




exit

cli-org2 的安装基本相同，自行登录cli-org2容器中安装

#之后只用拷贝到文件里去就行了
docker cp /root/fabcar.tar.gz cli-org2:/root/hyperledger/org2/peer1/assets/chaincode
#进入cli-org1
docker exec -it cli-org2 bash
cd /root/hyperledger/org2/peer1/assets/chaincode
export CORE_PEER_ADDRESS=peer1-org2:7051
export CORE_PEER_MSPCONFIGPATH=/root/hyperledger/org2/admin/msp
peer lifecycle chaincode install fabcar.tar.gz

exit

7.2 链码查询

peer lifecycle chaincode queryinstalled
packageid: fabcar_1:2fa9ca83f9294c7519f32c5dc27c1948ba7aa50093abdbd84415e78a1aeccd0e

7.3 链码批准

docker exec -it cli-org1 bash

export VERSION=1
export PACKAGE_ID=fabcar_1:2fa9ca83f9294c7519f32c5dc27c1948ba7aa50093abdbd84415e78a1aeccd0e
export ORDERER_CA=/root/hyperledger/org0/orderer/tls-msp/tlscacerts/tls-0-0-0-0-7052.pem
export CHANNEL_NAME=mychannel
export CORE_PEER_MSPCONFIGPATH=/root/hyperledger/org1/admin/msp

peer lifecycle chaincode approveformyorg -o orderer1-org0:7050 --ordererTLSHostnameOverride orderer1-org0 --tls --cafile ${ORDERER_CA} --channelID ${CHANNEL_NAME} --name fabcar1 --version ${VERSION} --init-required --package-id ${PACKAGE_ID} --sequence ${VERSION}

peer lifecycle chaincode checkcommitreadiness --channelID $CHANNEL_NAME --name fabcar1 --version ${VERSION} --sequence ${VERSION} --output json --init-required

exit

同理cli-org2授权基本相同

docker exec -it cli-org2 bash

export VERSION=1
export PACKAGE_ID=fabcar_1:2fa9ca83f9294c7519f32c5dc27c1948ba7aa50093abdbd84415e78a1aeccd0e
export ORDERER_CA=/root/hyperledger/org0/orderer/tls-msp/tlscacerts/tls-0-0-0-0-7052.pem
export CHANNEL_NAME=mychannel
export CORE_PEER_MSPCONFIGPATH=/root/hyperledger/org2/admin/msp

peer lifecycle chaincode approveformyorg -o orderer1-org0:7050 --ordererTLSHostnameOverride orderer1-org0 --tls --cafile ${ORDERER_CA} --channelID ${CHANNEL_NAME} --name fabcar1 --version ${VERSION} --init-required --package-id ${PACKAGE_ID} --sequence ${VERSION}

peer lifecycle chaincode checkcommitreadiness --channelID $CHANNEL_NAME --name fabcar1 --version ${VERSION} --sequence ${VERSION} --output json --init-required

exit

7.4 提交链码定义

docker exec -it cli-org1 bash
export CHANNEL_NAME=mychannel
export VERSION=1
export ORDERER_CA=/root/hyperledger/org0/orderer/tls-msp/tlscacerts/tls-0-0-0-0-7052.pem
export CORE_PEER_MSPCONFIGPATH=/root/hyperledger/org1/admin/msp

peer lifecycle chaincode commit -o orderer1-org0:7050 --ordererTLSHostnameOverride orderer1-org0 --tls --cafile $ORDERER_CA --channelID $CHANNEL_NAME --name fabcar1 --peerAddresses peer1-org1:7051 --tlsRootCertFiles /root/hyperledger/org1/peer1/tls-msp/tlscacerts/tls-0-0-0-0-7052.pem  --peerAddresses peer1-org2:7051 --tlsRootCertFiles /root/hyperledger/org2/peer1/tls-msp/tlscacerts/tls-0-0-0-0-7052.pem --version ${VERSION} --sequence ${VERSION} --init-required


peer chaincode list --installed
exit
#只用提交一次吧？,cli2不用提交了
#-------cli-org2-----
docker exec -it cli-org2 bash

export CHANNEL_NAME=mychannel
export VERSION=1
export ORDERER_CA=/root/hyperledger/org0/orderer/tls-msp/tlscacerts/tls-0-0-0-0-7052.pem
export CORE_PEER_MSPCONFIGPATH=/root/hyperledger/org2/admin/msp

peer lifecycle chaincode commit -o orderer1-org0:7050 --ordererTLSHostnameOverride orderer1-org0 --tls --cafile $ORDERER_CA --channelID $CHANNEL_NAME --name fabcar --peerAddresses peer1-org1:7051 --tlsRootCertFiles /root/hyperledger/org1/peer1/tls-msp/tlscacerts/tls-0-0-0-0-7052.pem  --peerAddresses peer1-org2:7051 --tlsRootCertFiles /root/hyperledger/org2/peer1/tls-msp/tlscacerts/tls-0-0-0-0-7052.pem --version ${VERSION} --sequence ${VERSION} --init-required

查询提交内容

export CHANNEL_NAME=mychannel
peer lifecycle chaincode querycommitted --channelID $CHANNEL_NAME --name fabcar
peer lifecycle chaincode queryapproved -C mychannel -n fabcar

7.5 初始化链码

docker exec -it cli-org1 bash
export CHANNEL_NAME=mychannel
export VERSION=1
export ORDERER_CA=/root/hyperledger/org0/orderer/tls-msp/tlscacerts/tls-0-0-0-0-7052.pem
export CORE_PEER_MSPCONFIGPATH=/root/hyperledger/org1/admin/msp

peer chaincode invoke -o orderer1-org0:7050 --ordererTLSHostnameOverride orderer1-org0 --tls --cafile $ORDERER_CA -C $CHANNEL_NAME -n fabcar1 --isInit --peerAddresses peer1-org1:7051 --tlsRootCertFiles /root/hyperledger/org1/peer1/tls-msp/tlscacerts/tls-0-0-0-0-7052.pem  --peerAddresses peer1-org2:7051 --tlsRootCertFiles /root/hyperledger/org2/peer1/tls-msp/tlscacerts/tls-0-0-0-0-7052.pem  -c '{"function":"initLedger","Args":[]}'

查询

peer chaincode query -C $CHANNEL_NAME -n fabcar1 -c '{"Args":["queryAllCars"]}'

脚本文件

start.sh文件

export COMPOSE_PROJECT_NAME=net

export doc_com=$(pwd)
docker-compose -f ${doc_com}/fabric-ca-tls/docker-compose.yaml -f ${doc_com}/org0/ca/docker-compose.yaml -f ${doc_com}/org0/orderer/docker-compose.yaml -f ${doc_com}/org1/ca/docker-compose.yaml -f ${doc_com}/org1/peer1/docker-compose.yaml -f ${doc_com}/org1/peer2/docker-compose.yaml -f ${doc_com}/org1/cli/docker-compose.yaml -f ${doc_com}/org2/ca/docker-compose.yaml -f ${doc_com}/org2/peer1/docker-compose.yaml -f ${doc_com}/org2/peer2/docker-compose.yaml -f ${doc_com}/org2/cli/docker-compose.yaml up -d


export COMPOSE_PROJECT_NAME=net

export doc_com=$(pwd)
echo ${doc_com}/fabric-ca-tls
cd fabric-ca-tls
docker-compose up -d
sleep 1

echo ${doc_com}/org0/ca
cd ${doc_com}/org0/ca
docker-compose up -d
sleep 1

echo ${doc_com}/org0/orderer
cd ${doc_com}/org0/orderer
docker-compose up -d
sleep 1

echo ${doc_com}/org1/ca
cd ${doc_com}/org1/ca
docker-compose up -d
sleep 1

echo ${doc_com}/org1/peer1
cd ${doc_com}/org1/peer1
docker-compose up -d
sleep 1

echo ${doc_com}/org1/peer2
cd ${doc_com}/org1/peer2
docker-compose up -d
sleep 1

echo ${doc_com}/org1/cli
cd ${doc_com}/org1/cli
docker-compose up -d
sleep 1

echo ${doc_com}/org2/ca
cd ${doc_com}/org2/ca
docker-compose up -d
sleep 1

echo ${doc_com}/org2/peer1
cd ${doc_com}/org2/peer1
docker-compose up -d
sleep 1

echo ${doc_com}/org2/peer2
cd ${doc_com}/org2/peer2
docker-compose up -d
sleep 1

echo ${doc_com}/org2/cli
cd ${doc_com}/org2/cli
docker-compose up -d

down.sh文件

docker kill $(docker ps -a -q) || true
sleep 1
docker rm $(docker ps -a -q) || true

stop.sh

docker stop $(docker ps -a -q) || true

6.1 链码安装

cli-org1安装

#之后只用拷贝到文件里去就行了
docker cp /home/pi/Desktop/simple.tar.gz cli-org1:/root/hyperledger/org1/peer1/assets/chaincode
#进入cli-org1
docker exec -it cli-org1 bash
cd /root/hyperledger/org1/peer1/assets/chaincode
export CORE_PEER_ADDRESS=peer1-org1:7051
export CORE_PEER_MSPCONFIGPATH=/root/hyperledger/org1/admin/msp
peer lifecycle chaincode install simple.tar.gz


exit

cli-org2 的安装基本相同，自行登录cli-org2容器中安装

#之后只用拷贝到文件里去就行了
docker cp /home/pi/Desktop/simple.tar.gz cli-org2:/root/hyperledger/org2/peer1/assets/chaincode
#进入cli-org1
docker exec -it cli-org2 bash
cd /root/hyperledger/org2/peer1/assets/chaincode
export CORE_PEER_ADDRESS=peer1-org2:7051
export CORE_PEER_MSPCONFIGPATH=/root/hyperledger/org2/admin/msp

peer lifecycle chaincode install simple.tar.gz

exit

6.2 链码查询

peer lifecycle chaincode queryinstalled
packageid: simple_1:9b72d7f1eda5c57c0f1a71bf739507db9e2581a036474f12b252e15346a381ea

6.3 链码批准

docker exec -it cli-org1 bash

export VERSION=1
export PACKAGE_ID=simple_1:9b72d7f1eda5c57c0f1a71bf739507db9e2581a036474f12b252e15346a381ea
export ORDERER_CA=/root/hyperledger/org0/orderer/tls-msp/tlscacerts/tls-0-0-0-0-7052.pem
export CHANNEL_NAME=mychannel
export CORE_PEER_MSPCONFIGPATH=/root/hyperledger/org1/admin/msp

peer lifecycle chaincode approveformyorg -o orderer1-org0:7050 --ordererTLSHostnameOverride orderer1-org0 --tls --cafile ${ORDERER_CA} --channelID ${CHANNEL_NAME} --name simple --version ${VERSION} --package-id ${PACKAGE_ID} --sequence ${VERSION} --waitForEvent

peer lifecycle chaincode checkcommitreadiness --channelID $CHANNEL_NAME --name simple --version ${VERSION} --sequence ${VERSION} --output json

exit

同理cli-org2授权基本相同

docker exec -it cli-org2 bash

export VERSION=1
export PACKAGE_ID=simple_1:9b72d7f1eda5c57c0f1a71bf739507db9e2581a036474f12b252e15346a381ea
export ORDERER_CA=/root/hyperledger/org0/orderer/tls-msp/tlscacerts/tls-0-0-0-0-7052.pem
export CHANNEL_NAME=mychannel
export CORE_PEER_MSPCONFIGPATH=/root/hyperledger/org2/admin/msp

peer lifecycle chaincode approveformyorg -o orderer1-org0:7050 --ordererTLSHostnameOverride orderer1-org0 --tls --cafile ${ORDERER_CA} --channelID ${CHANNEL_NAME} --name simple --version ${VERSION}  --package-id ${PACKAGE_ID} --sequence ${VERSION} --waitForEvent

peer lifecycle chaincode checkcommitreadiness --channelID $CHANNEL_NAME --name simple --version ${VERSION} --sequence ${VERSION} --output json

exit

6.4 提交链码定义

docker exec -it cli-org1 bash
export CHANNEL_NAME=mychannel
export VERSION=1
export ORDERER_CA=/root/hyperledger/org0/orderer/tls-msp/tlscacerts/tls-0-0-0-0-7052.pem
export CORE_PEER_MSPCONFIGPATH=/root/hyperledger/org1/admin/msp

peer lifecycle chaincode commit -o orderer1-org0:7050 --ordererTLSHostnameOverride orderer1-org0 --tls --cafile $ORDERER_CA --channelID $CHANNEL_NAME --name simple --peerAddresses peer1-org1:7051 --tlsRootCertFiles /root/hyperledger/org1/peer1/tls-msp/tlscacerts/tls-0-0-0-0-7052.pem  --peerAddresses peer1-org2:7051 --tlsRootCertFiles /root/hyperledger/org2/peer1/tls-msp/tlscacerts/tls-0-0-0-0-7052.pem --version ${VERSION} --sequence ${VERSION}

exit
#只用提交一次吧？
peer chaincode list --installed
#-------cli-org2-----
docker exec -it cli-org2 bash

export CHANNEL_NAME=mychannel
export VERSION=1
export ORDERER_CA=/root/hyperledger/org0/orderer/tls-msp/tlscacerts/tls-0-0-0-0-7052.pem
export CORE_PEER_MSPCONFIGPATH=/root/hyperledger/org2/admin/msp

peer lifecycle chaincode commit -o orderer1-org0:7050 --ordererTLSHostnameOverride orderer1-org0 --tls --cafile $ORDERER_CA --channelID $CHANNEL_NAME --name simple --peerAddresses peer1-org1:7051 --tlsRootCertFiles /root/hyperledger/org1/peer1/tls-msp/tlscacerts/tls-0-0-0-0-7052.pem  --peerAddresses peer1-org2:7051 --tlsRootCertFiles /root/hyperledger/org2/peer1/tls-msp/tlscacerts/tls-0-0-0-0-7052.pem --version ${VERSION} --sequence ${VERSION}

查询提交内容

export CHANNEL_NAME=mychannel
peer lifecycle chaincode querycommitted --channelID $CHANNEL_NAME --name simple
peer lifecycle chaincode queryapproved -C mychannel -n simple

6.5 初始化链码

docker exec -it cli-org1 bash
export CHANNEL_NAME=mychannel
export VERSION=1
export ORDERER_CA=/root/hyperledger/org0/orderer/tls-msp/tlscacerts/tls-0-0-0-0-7052.pem
export CORE_PEER_MSPCONFIGPATH=/root/hyperledger/org1/admin/msp

peer chaincode invoke -o orderer1-org0:7050 --ordererTLSHostnameOverride orderer1-org0 --tls --cafile $ORDERER_CA -C $CHANNEL_NAME -n simple --peerAddresses peer1-org1:7051 --tlsRootCertFiles /root/hyperledger/org1/peer1/tls-msp/tlscacerts/tls-0-0-0-0-7052.pem  --peerAddresses peer1-org2:7051 --tlsRootCertFiles /root/hyperledger/org2/peer1/tls-msp/tlscacerts/tls-0-0-0-0-7052.pem --isInit -c '{"function":"initLedger","Args":[]}'

peer chaincode invoke -o orderer1-org0:7050 --ordererTLSHostnameOverride orderer1-org0 --tls --cafile $ORDERER_CA -C $CHANNEL_NAME -n simple --peerAddresses peer1-org1:7051 --tlsRootCertFiles /root/hyperledger/org1/peer1/tls-msp/tlscacerts/tls-0-0-0-0-7052.pem  --peerAddresses peer1-org2:7051 --tlsRootCertFiles /root/hyperledger/org2/peer1/tls-msp/tlscacerts/tls-0-0-0-0-7052.pem -c '{"function":"Create","Args":["a","10"]}'

查询

peer chaincode query -C mychannel -n simple -c '{"Args":["Read","a"]}'
dockerFabricfabric-ca
暂无评论

发送评论 编辑评论





































































































|´・ω・)ノ


ヾ(≧∇≦*)ゝ


(☆ω☆)


（╯‵□′）╯︵┴─┴


￣﹃￣


(/ω＼)


∠( ᐛ 」∠)＿


(๑•̀ㅁ•́ฅ)


→_→


୧(๑•̀⌄•́๑)૭


٩(ˊᗜˋ*)و


(ノ°ο°)ノ


(´இ皿இ｀)


⌇●﹏●⌇


(ฅ´ω`ฅ)


(╯°A°)╯︵○○○


φ(￣∇￣o)


ヾ(´･ ･｀｡)ノ"


( ง ᵒ̌皿ᵒ̌)ง⁼³₌₃


(ó﹏ò｡)


Σ(っ °Д °;)っ


( ,,´･ω･)ﾉ"(´っω･｀｡)


╮(╯▽╰)╭


o(*////▽////*)q


＞﹏＜


( ๑´•ω•) "(ㆆᴗㆆ)






😂


😀


😅


😊


🙂


🙃


😌


😍


😘


😜


😝


😏


😒


🙄


😳


😡


😔


😫


😱


😭


💩


👻


🙌


🖕


👍


👫


👬


👭


🌚


🌝


🙈


💊


😶


🙏


🍦


🍉


😣






































































Source: github.com/k4yt3x/flowerhd







颜文字


Emoji


小恐龙


花!





















上一篇




下一篇









			        推荐文章







Hyperledger Fabric总集合







京东签到







应用程序开发







链码开发学习







fabric压力测试
